- A: 2x Raspberry Pi 4B (2 GB RAM, 120 GB USB SSD) Network Services 1
-- HAProxy
-- BIND9 (Secondary DNS internal domains)
-- Wireguard (to VPS)
-- RADVD (to announce network to VPS)
- B: 2x Orange Pi 3 LTS (2GB RAM, 8GB eMMC) Network Services 2
-- Pi-hole (on Docker) (Client DNS)
-- Kea DHCP-server
-- Tayga (NAT64)
-- RADVD (to announce NAT64 network)
- C: 1x Orange Pi 4 Pro (12 GB RAM, 2 TB USB SSD) Infastructure Docker
-- Heimdall (startpage infrastructure)
-- Technitium DNS (primare DNS all domains)
-- Omada Controller (Wifi management)
-- Vaultwarden (password management)
-- apt-chacher-ng (apt proxy and cache)
-- docker registry ????
-- docs-wikijs (documentation)
-- guacamole
-- osTicket
- D: 1x Orange Pi 4A (4 GB RAM, 120 GB USB SSD) Infrastructure Incus
-- Webhooks
-- Netbox
-- Ansible
- E: 1x Raspberry Pi 5 (8 GB RAM, 128 GB USB SSD) Infrastructure Monitoring Docker
-- Grafana
-- netdata
-- netflow
-- uptime-kuma
-- Dozzle (Docker monitoring)
-- akvorado
-- elastic-netflow
- F: 1x Raspberry Pi 4 (8 GB RAM, .... USB SSD) Docker Home Assistant
-- home-assistant
-- esphome
-- mosquitto
-- mqtt explorer
-- zigbee2mqtt
- G: 1x Raspberry Pi 5 (8 GB RAM, 2 TB USB SSD) Docker End user data
-- Immich
-- Nextcloud
-- podcasts
-- Vikunja
-- dokuwiki
-- hiemdall
-- linkding
-- projectsend
-- transmission
-- ctfd
- H: 1x Orange Pi 3 LTS (2 GB RAM, 8 GB eMMC, USB storage) Multimedia Storage
-- Samba
- I: 3x Raspberry Pi 4B (4 GB RAM, 256 GB USB storage) Web Cluster
-- Galera
-- LAMP
- 3x TP-Link Access Points
-- SSID: LANESTRAAT = VLAN 10 (= PC's) (= IPv6 Mostly)
-- SSID: LANESTRAAT-IOT = VLAN 30
-- SSID: LANESTRAAT-MM = VLAN 40 (bedoeld voor Multimedia)
-- SSID: LANESTRAAT-GUEST = VLAN 50 (gasten, enkel internettoegang) IPv6 Mostly
- Switches
-- VLAN 10 = Wireless PC's IPv6 MOSTLY
-- VLAN 20 = Servers IPv6 ONLY
-- VLAN 30 = IOT = Dual Stack
-- VLAN 40 = Multimedia = Dual Stack
-- VLAN 50 = Guest network (= geen toegang tot servers, enkel internet) IPv6 Mostly
-- VLAN 60 = Cisco LAB
- bekabeling
-- 2 port SBC 2.5 Gbps
-- Switch
** AP Inkom
** Switch 108E printer
** Switch 108E garage
** Switch ES224G traphal
